Xi'an Dongmeng Group Co., Ltd. is one of the most reliable manufacturers and suppliers of 1100 aluminum foil in China, also supports customized service. With abundant experience, we warmly welcome you to wholesale cheap products in stock here and get free sample from our factory. For price consultation, contact us.
1100 aluminum foil introduction
1100 aluminum foil is an aluminum foil made of 99% pure aluminum, containing no more than 1% of other chemical elements. It has good formability, corrosion resistance, and is easy to process and shape.
The processed aluminum-plastic panels have the characteristics of weather resistance, corrosion resistance, fire resistance, moisture resistance, sound insulation, heat insulation, light weight, easy processing, and convenient transportation and installation.
1100 aluminum foil is widely used in heat exchangers in the refrigeration industry, storage containers in the chemical and food industries, and capacitor shell materials in the electronics industry due to its good performance.
Specifications
| Elements | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al |
| Content | 0.95 | 0.05-0.2 | 0.05 | – | – | 0.1 | – | 0.15 | Remain | |
| Typical alloy | 1100 Aluminum Foil | |||||||||
| Material temper | F,O,H14,H16,H18,H19,H22,H24,H26,H28 | |||||||||
| Thickness (mm) | 0.006-0.2 | |||||||||
| Width (mm) | 100-1600 | |||||||||
| Length (mm) | Customize | |||||||||
| Typical product | Electrolytic capacitor, Food industry packaging, etc | |||||||||
1000 series aluminum alloy chemical composition comparison
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr | Al |
| 1235 | ≤0.65 (Fe+Si) | ≤0.05 | ≤0.05 | ≤0.05 | – | – | ≤0.10 | ≤0.03 | – | ≥99.35 | |
| 1145 | ≤0.55 (Fe+Si) | ≤0.05 | ≤0.05 | ≤0.05 | – | – | ≤0.05 | ≤0.03 | – | ≥99.45 | |
| 1050 | ≤0.25 | ≤0.40 | ≤0.05 | ≤0.05 | ≤0.05 | – | – | ≤0.05 | ≤0.03 | – | ≥99.50 |
| 1060 | ≤0.25 | ≤0.35 | ≤0.05 | ≤0.03 | ≤0.03 | – | – | ≤0.05 | ≤0.03 | – | ≥99.60 |
| 1070 | ≤0.20 | ≤0.25 | ≤0.04 | ≤0.03 | ≤0.03 | – | – | ≤0.04 | ≤0.03 | – | ≥99.70 |
Advantages of 1100 aluminum foil
The surface of the 1100 aluminum foil is uniform in color, clean, and flat in shape, with no obvious roller marks, pitting, pinholes, or corrosion marks
There are no rolling defects such as creases, spots, bright lines, etc. on the surface of the aluminum foil
There is no color difference on the surface of aluminum foil
There is no oil on the surface, no serious oil smell, and no oil spots visible to the naked eye
Strong mechanical properties, high blast resistance, puncture resistance and tear resistance
Surface tension, dyne pen test shall not be less than 32 dyne
Mechanical properties of 1100 aluminium foil
| Alloy | Temper | Thickness (mm) |
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
Cupping test value I.E/mm |
| 1100 | O | 0.08-0.10 | 80-110 | ≥50 | ≥18 | ≥6.0 |
| 0.10-0.20 | 80-110 | ≥50 | ≥20 | ≥6.5 | ||
| H22 | 0.08-0.10 | 100-130 | ≥60 | ≥18 | ≥5.5 | |
| 0.10-0.20 | 100-130 | ≥60 | ≥20 | ≥6.0 | ||
| H24 | 0.08-0.10 | 115-145 | ≥70 | ≥15 | ≥5.0 | |
| 0.10-0.20 | 115-145 | ≥70 | ≥18 | ≥5.5 | ||
| H26 | 0.08-0.10 | 130-160 | ≥90 | ≥8 | ≥4.0 | |
| 0.10-0.20 | 130-160 | ≥90 | ≥10 | ≥4.5 | ||
| H18 | 0.08-0.20 | ≥160 | – | ≥1 | – |
Outstanding Properties
High Purity
1100 aluminum foil is characterized by its high aluminum content, typically around 99.0% or higher. This high purity contributes to its excellent chemical stability. It is resistant to corrosion in many common environments, making it suitable for applications where exposure to moisture, air, or certain chemicals is inevitable. For example, in the packaging of some chemical products or in humid industrial settings, 1100 aluminum foil can maintain its integrity and performance over time.
Excellent Formability
One of the key advantages of 1100 aluminum foil is its exceptional formability. It can be easily bent, folded, stamped, and rolled into various shapes without losing its structural integrity. This property allows for great flexibility in manufacturing processes. Whether it's for creating intricate packaging designs or forming specific components, 1100 aluminum foil can adapt to different production requirements with ease.
Good Thermal Conductivity
1100 aluminum foil exhibits good thermal conductivity. This makes it useful in applications where heat transfer is important. In cooking utensils, for instance, it can help in evenly distributing heat, ensuring that food is cooked uniformly. In some industrial heat - exchange systems, it can play a role in facilitating efficient heat transfer.
Smooth Surface and Bright Appearance
The surface of 1100 aluminum foil is smooth and has a bright, silvery appearance. This not only enhances its aesthetic appeal but also makes it suitable for applications where a clean and attractive surface is required. It can be easily printed on, allowing for the addition of logos, instructions, or other information, which is beneficial for branding and product identification.
