Custom Stainless Steel Sheet Metal Fabrication
Dongmeng Group manufactures custom stainless steel sheet metal parts through drawing-based cutting, bending and fabrication.
Available materials include 201, 304, 316L and 430 stainless steel. We support standard sheet supply, cut-to-size blanks, bent components, brackets, panels, covers, enclosures and other customized parts for industrial, architectural and commercial projects.
Processing requirements are reviewed according to the material grade, thickness, part geometry, bend direction, surface requirement, tolerance, quantity and final application.
What Is Stainless Steel Sheet Metal Fabrication?
Stainless steel sheet metal fabrication is the process of converting flat stainless steel sheets into finished parts or assemblies through cutting, bending, punching, drilling, welding and forming.
Unlike purchasing standard full sheets, custom fabrication allows buyers to receive components manufactured according to their drawings and assembly requirements.
Typical fabricated products include:
Brackets
Mounting plates
Equipment panels
Machine guards
Cabinets
Enclosures
Covers
Trays
Frames
Decorative panels
Kitchen components
Elevator components
Architectural metal parts
The correct production route depends on the stainless steel grade, sheet thickness, part geometry, quantity, surface requirement and dimensional tolerance.
Stainless Steel Sheet Metal Fabrication Specifications
| Item | Available Options |
| Service | Custom stainless steel sheet metal fabrication |
| Manufacturer | Dongmeng Group |
| Material Grades | 201, 304, 316L and 430 |
| Sheet Thickness | 0.3–2.0 mm |
| Standard Sheet Size | 1000 × 2000 mm |
| Standard Sheet Size | 1219 × 2438 mm |
| Standard Sheet Size | 1219 × 3048 mm |
| Customized Size | According to drawing and material availability |
| Cutting Services | Laser cutting, shearing and cut-to-size production |
| Bending Services | Press brake bending and customized forming |
| Additional Processing | Punching, drilling, welding, deburring and edge finishing |
| Surface Finish | Confirmed according to raw material and final application |
| Protective Film | PE or PVC where required |
| Drawing Formats | PDF, DXF, DWG and STEP preferred |
| Inspection | Material, dimensions, hole positions, bend angles, surface and packaging |
| Documentation | Material Test Certificate available according to order requirements |
| Third-Party Inspection | Available upon request |
| Packaging | Waterproof wrapping, wooden crates or steel pallets |
| Production Time | Confirmed after drawing, quantity and processing review |
Important Tolerance Note
There is no single tolerance that applies to every stainless steel fabricated part.
Achievable tolerances depend on:
Material thickness
Part dimensions
Cutting method
Bend length
Bend radius
Number of bends
Hole positions
Welding requirements
Surface finish
Inspection method
Critical dimensions and tolerances must be clearly marked on the drawing and confirmed before production.
What Is Stainless Steel Sheet Metal Fabrication?
Stainless steel sheet metal fabrication is the process of converting flat stainless steel sheets into finished parts or assemblies through cutting, bending, punching, drilling, welding and forming.
Unlike purchasing standard full sheets, custom fabrication allows buyers to receive components manufactured according to their drawings and assembly requirements.
Typical fabricated products include:
Brackets
Mounting plates
Equipment panels
Machine guards
Cabinets
Enclosures
Covers
Trays
Frames
Decorative panels
Kitchen components
Elevator components
Architectural metal parts
The correct production route depends on the stainless steel grade, sheet thickness, part geometry, quantity, surface requirement and dimensional tolerance.
Stainless Steel Cutting Services
Laser Cutting
Laser cutting is suitable for producing customized profiles, holes, slots and complex shapes from stainless steel sheet.
It is commonly used for:
Brackets
Flat blanks
Equipment panels
Ventilation patterns
Mounting plates
Decorative components
Enclosure parts
Prototype components
Repeated production parts
Before production, the drawing should clearly identify:
Finished part dimensions
Hole diameters
Slot dimensions
Internal and external contours
Critical tolerances
Visible surface
Protective film requirements
Quantity
Very small holes, narrow slots and closely spaced features should be reviewed in relation to the sheet thickness and production method.
Shearing and Cut-to-Size Production
Shearing is commonly used for straight cuts and rectangular blanks.
It can be suitable when buyers require:
Rectangular panels
Cabinet blanks
Wall panels
Simple covers
Standard strips
Straight-edge components
Material prepared for later bending
Shearing requirements should specify the finished width, length, squareness and edge condition.
Punching and Drilling
Punching or drilling may be used for:
Mounting holes
Ventilation holes
Fastener positions
Repeated hole patterns
Access openings
Assembly features
Hole diameter, spacing and distance from bends or edges should be reviewed before production.
Deburring and Edge Finishing
Cut stainless steel parts may require deburring or edge finishing according to their final use.
Available requirements may include:
Removal of sharp edges
Light edge breaking
Burr reduction
Edge polishing
Preparation for welding
Preparation for assembly
The required edge condition should be stated on the drawing or purchase specification.
Stainless Steel Bending Services
Press Brake Bending
Press brake bending is used to form flat stainless steel blanks into angular components.
Typical products include:
L-shaped brackets
U-shaped channels
Z-shaped profiles
Trays
Covers
Cabinets
Enclosure panels
Frames
Architectural trims
Machine components
The bending result depends on:
Material grade
Sheet thickness
Bend radius
Bend angle
Flange length
Bend direction
Tooling
Grain direction
Springback
Number and sequence of bends
Bend Radius
The inside bend radius should be specified wherever it is functionally or visually important.
An extremely small bend radius may increase the risk of:
Surface marking
Material cracking
Distortion
Dimensional instability
Tooling interference
The required radius should be reviewed against the material grade, thickness and bending direction.
Bend Direction
For brushed, hairline or otherwise directional surfaces, drawings must identify the visible side and grain direction after bending.
The grain direction on the flat blank may not match the desired visual direction on the finished component unless it is planned before cutting.
Springback
Stainless steel can recover slightly after the bending force is removed.
This effect is known as springback.
The amount of springback depends on the stainless steel grade, thickness, bend radius, tool selection and forming method. Bend angles should therefore be confirmed through the agreed production process rather than assumed from the flat drawing alone.
Available Stainless Steel Grades
201 Stainless Steel
Grade 201 is an economical material for selected indoor components in relatively dry environments.
It may be considered for:
Interior decorative parts
Cabinets
Furniture components
Covers
Displays
Cost-sensitive indoor assemblies
Grade 201 should be evaluated carefully for humid, coastal or chemically aggressive environments.
304 Stainless Steel
Grade 304 offers a practical balance of corrosion resistance, formability and cost.
It is commonly selected for:
Equipment panels
Commercial kitchen components
Cabinets and enclosures
Architectural parts
Brackets
Trays
Interior and general-purpose fabricated components
Grade 304 is normally the starting recommendation for general stainless steel sheet metal fabrication.
316L Stainless Steel
Grade 316L provides improved corrosion resistance for more demanding environments.
It may be selected for:
Coastal projects
Marine-related applications
High-humidity environments
Chemical processing components
Food and hygienic equipment
Exterior components
Chloride-exposed locations
The final grade should be selected according to the actual chemicals, temperature, cleaning method and service environment.
430 Stainless Steel
Grade 430 is a magnetic ferritic stainless steel commonly used for selected indoor applications.
It may be considered for:
Appliance components
Equipment covers
Indoor cabinets
Decorative parts
Dry interior environments
Applications requiring magnetic stainless steel
Grade 430 is generally not the first choice for coastal or heavily corrosive environments.
Material Selection Guide
| Application | Recommended Starting Grade | Main Consideration |
| General indoor fabricated parts | 304 | Formability and general corrosion resistance |
| Cost-sensitive dry indoor components | 201 or 430 | Environmental limitations |
| Commercial kitchen components | 304 | Moisture and cleaning requirements |
| Coastal or marine-related parts | 316L | Chloride exposure |
| High-humidity components | 304 or 316L | Moisture and maintenance |
| Appliance components | 430 | Indoor use and magnetic properties |
| Architectural decorative parts | 304 | Appearance and fabrication |
| Chemical-service components | 316L or project-specific alloy | Actual chemical exposure |
This table is an initial selection guide only.
Send Dongmeng Group the working environment, temperature, cleaning method and expected service conditions for material review.
Design for Manufacturing Review
A drawing can appear complete from a design perspective but still require changes before cutting and bending.
Dongmeng Group reviews the following items before production.
Material and Thickness
Specify:
Stainless steel grade
Sheet thickness
Material standard, where required
Surface finish
Visible side
Protective film requirement
Overall Dimensions
Clearly identify the finished dimensions of the part.
Do not rely only on image scale or unspecified CAD geometry.
Critical Tolerances
Mark only dimensions that are functionally critical.
Overly tight tolerances on non-critical features may increase inspection requirements, production difficulty and cost.
Bend Radius and Bend Angle
Specify the required inside radius and finished angle where these affect assembly or appearance.
Flange Length
Very short flanges may interfere with standard bending tools.
Flange dimensions should be reviewed before finalizing the flat pattern.
Hole-to-Bend Distance
Holes placed too close to a bend may deform during forming.
Critical holes near bends should be identified for production review.
Corner Relief
Bent enclosures, trays and multi-flange parts may require corner relief to reduce tearing, overlap or distortion.
Grain Direction
For brushed or directional stainless steel, mark the required grain direction on each visible face.
Weld Requirements
Where welding is required, specify:
Weld location
Weld type
Continuous or intermittent welding
Visible weld requirements
Grinding or polishing requirements
Leak-tight requirements, where applicable
Assembly Requirements
Indicate whether the parts will be:
Welded
Bolted
Riveted
Inserted
Hinged
Sealed
Assembled with other components
Quantity
State prototype, trial batch and expected production quantity.
The preferred production method can change significantly between a single prototype and a repeated batch.
Recommended Drawing Information
For an accurate factory quotation, provide:
Part name
Stainless steel grade
Sheet thickness
Finished dimensions
Critical tolerances
Hole and slot dimensions
Bend angles
Inside bend radius
Visible surface
Surface finish
Grain direction
Weld requirements
Edge requirements
Quantity
Inspection requirements
Packaging requirements
Destination country or port
Required delivery date
Preferred File Formats
PDF for readable dimensions and notes
DXF or DWG for flat cutting profiles
STEP for three-dimensional formed parts
Reference photographs for appearance clarification
A CAD file should be accompanied by a dimensioned PDF whenever possible.
Typical Custom Stainless Steel Parts
Brackets and Mounting Components
Custom brackets may include:
L brackets
U brackets
Z brackets
Mounting plates
Reinforcement plates
Equipment supports
Important requirements include hole location, bend angle, flange length and load direction.
Cabinets and Enclosures
Stainless steel cabinets and enclosures may require:
Laser-cut openings
Multiple bends
Welded corners
Door or hinge preparation
Cable openings
Ventilation patterns
Surface protection
The visible side and finishing requirements should be identified before fabrication.
Equipment Panels and Covers
Panels and covers are commonly used for machinery, food equipment, electrical systems and commercial installations.
Buyers should confirm:
Dimensions
Flatness
Mounting holes
Cutouts
Edge condition
Protective film
Surface finish
Trays and Formed Components
Trays may require close review of:
Corner design
Bend sequence
Welded or open corners
Drainage
Edge condition
Cleaning requirements
Leak-tight requirements
Architectural and Decorative Parts
Decorative parts may use brushed, hairline or other visible stainless steel surfaces.
These projects often require additional control of:
Grain direction
Surface uniformity
Protective film
Bend marking
Weld finishing
Packaging
Installation sequence
Applications
Custom stainless steel sheet metal components can be manufactured for:
Commercial kitchen equipment
Food processing equipment
Machinery and industrial equipment
Electrical cabinets
Control panels
Architectural metalwork
Elevator components
Building interiors
Retail fixtures
Hotel projects
Furniture
Appliance components
Automotive and transportation equipment
Chemical and processing equipment
Custom OEM assemblies
The material grade and manufacturing route should be selected according to the final environment and functional requirements.
Factory Production Workflow
1. Drawing Review
The Dongmeng Group team reviews the material, dimensions, tolerances, bends, holes, finish and quantity.
2. Production Route Confirmation
The appropriate cutting, bending and additional processing route is selected.
3. Material Preparation
The required stainless steel grade, thickness and sheet condition are confirmed.
4. Cutting
The flat profile is produced according to the approved drawing.
5. Deburring and Preparation
Edges and features are prepared according to the required finish and subsequent manufacturing steps.
6. Bending and Forming
Components are bent according to the required sequence, angle and radius.
7. Additional Fabrication
Punching, drilling, welding, grinding or other agreed processes are completed.
8. Inspection
Dimensions, holes, bends, surface condition and quantity are inspected according to the agreed specification.
9. Surface Protection
Protective film or additional packaging protection is applied where required.
10. Export Packaging
Parts are packed according to their dimensions, finish, quantity and transportation method.
Factory Quality Control
Quality requirements should be agreed before order confirmation.
Material Inspection
Inspection may include:
Stainless steel grade verification
Material certificate review
Sheet thickness measurement
Raw material identification
Batch traceability according to order requirements
Cutting Inspection
Inspection may include:
Overall dimensions
Hole dimensions
Hole positions
Slot dimensions
Profile shape
Edge condition
Burr condition
Bending Inspection
Inspection may include:
Bend angle
Flange dimensions
Inside radius
Overall formed dimensions
Part symmetry
Surface marking
Distortion
Welded-Part Inspection
Where applicable, inspection may include:
Weld position
Weld continuity
Overall assembly dimensions
Visual weld condition
Grinding and finishing condition
Surface Inspection
Inspection may include:
Scratches
Dents
Surface contamination
Grain direction
Visible-side condition
Protective film
Edge and corner condition
Available Documentation
Depending on the confirmed order requirements, documentation may include:
Material Test Certificate
Dimensional inspection report
Packing list
Commercial invoice
Certificate of Origin
Third-party inspection report
Third-party inspection requirements should be agreed before production.
Surface Protection and Export Packaging
Stainless steel sheet metal parts can be protected according to their surface condition and transportation requirements.
Surface Protection
Available methods may include:
PE protective film
PVC protective film
Paper interleaving
Foam separation
Edge protection
Corner protection
Packaging
Export packaging may include:
Waterproof wrapping
Reinforced cartons
Wooden crates
Steel pallets
Internal dividers
Metal or plastic strapping
Container securing
Decorative and fabricated parts should be packed to reduce metal-to-metal contact during transportation.
Handling Recommendations
Use clean gloves for visible stainless steel surfaces.
Avoid dragging parts across each other.
Keep stainless steel separate from carbon steel contamination.
Store products in a dry, covered area.
Protect formed corners and visible edges.
Remove protective film according to the agreed storage and installation conditions.
Why Choose Dongmeng Group?
Stainless Steel Manufacturing Factory
Dongmeng Group focuses on stainless steel sheet supply, cutting, bending and customized fabrication for international B2B projects.
Material and Fabrication from One Supplier
Customers can coordinate raw material, cutting, bending, additional fabrication, inspection and export packaging through one production supplier.
Drawing-Based Manufacturing
Parts are reviewed and manufactured according to customer drawings and confirmed technical requirements.
Multiple Stainless Steel Grades
Available grades include 201, 304, 316L and 430 for different applications, environments and budgets.
Customized Production
We support custom dimensions, holes, cutouts, bends and formed components according to drawing review.
Surface Protection
Protective film and separated packaging can be used for visible stainless steel surfaces.
Inspection Support
Material, dimensions, bend angles, surface condition and packaging can be inspected according to the agreed requirements.
Export Packaging
Products can be packed in reinforced cartons, wooden crates or steel pallets according to part size and transportation conditions.
Professional Quotation Review
The Dongmeng Group team reviews the material, drawing, tolerance, quantity, fabrication route, inspection and delivery destination before quotation.
Frequently Asked Questions
Is Dongmeng Group a stainless steel sheet metal fabrication manufacturer?
Yes. Dongmeng Group provides stainless steel sheet supply, cutting, bending and customized fabrication for drawing-based B2B orders.
What stainless steel grades are available?
Current options include 201, 304, 316L and 430.
The appropriate grade depends on corrosion exposure, forming requirements, appearance and budget.
What sheet thicknesses can you process?
The current published sheet thickness range is 0.3–2.0 mm.
Final feasibility depends on the grade, part geometry, bending requirements and selected process.
Can you manufacture parts according to drawings?
Yes. PDF, DXF, DWG and STEP files can be reviewed for quotation and production.
A dimensioned PDF should accompany the CAD file whenever possible.
What cutting services are available?
Available processing can include laser cutting, shearing and cut-to-size production.
The appropriate method is selected according to geometry, dimensions, thickness and quantity.
Can you bend stainless steel parts?
Yes. Press brake bending and customized forming can be reviewed according to the material, thickness, bend radius, flange length and part geometry.
What tolerances can you achieve?
Tolerance depends on the process, part size, material thickness, geometry and inspection method.
Critical tolerances must be marked on the drawing and confirmed before production.
Can you produce prototypes?
Prototype and trial orders can be reviewed according to the material, drawing, tooling requirements and production conditions.
Do not assume that prototype and production pricing will be identical.
Can you protect the visible surface?
PE or PVC protective film and separated packaging may be available for visible stainless steel surfaces.
The visible side should be marked on the drawing.
Can Dongmeng Group provide Material Test Certificates?
Material Test Certificates can be supplied according to the confirmed material and order requirements.
Is third-party inspection available?
Third-party inspection can be arranged upon request.
The agency, scope, timing and cost allocation should be agreed before production.
What is the minimum order quantity?
Minimum order quantity depends on the material grade, thickness, dimensions, process, quantity and current material availability.
Send your drawing for confirmation.
How long does production take?
Production time depends on material availability, drawing complexity, quantity, fabrication processes, inspection and packaging.
The confirmed schedule will be included in the quotation.
How do I receive an accurate quotation?
Provide the material grade, thickness, drawings, quantity, tolerance requirements, surface condition, destination and requested delivery date.
Request a Factory Quotation
Contact Dongmeng Group for custom stainless steel sheet metal cutting, bending and fabrication.
Please Send
PDF, DXF, DWG or STEP drawing
Stainless steel grade
Sheet thickness
Required quantity
Critical tolerances
Surface requirements
Destination country or port
Required delivery date
Phone / WeChat / WhatsApp
+86 157 6921 4734
Our Office Address
Room 4107, Runfeng Building
Sanqiao New Street, Weiyang District
Xi'an City, Shaanxi Province, China
Send your drawings and specifications to the Dongmeng Group team for manufacturing review.
Hot Tags: Custom Stainless Steel Sheet Metal Fabrication, China Custom Stainless Steel Sheet Metal Fabrication manufacturers, suppliers, factory, 20 Gauge 316 Stainless Steel Sheet, SS 316 Sheet Price Per KG, 316 2b Stainless Steel, Factory Wholesale High Quality 201 430 304 316 Stainless Steel Plate Sheet, 14 Inch 316 Stainless Steel Plate
