Xi'an Dongmeng Group Co., Ltd. is one of the most reliable manufacturers and suppliers of aisi 316ti in China, also supports customized service. With abundant experience, we warmly welcome you to wholesale cheap products in stock here and get free sample from our factory. For price consultation, contact us.
AISI 316Ti, also known as Titanium-Stabilized 316 Stainless Steel, UNS S31635, or EN 1.4571, is a premium austenitic stainless steel designed for exceptional corrosion resistance, high-temperature stability, and long-term durability. Perfect for chemical processing, marine environments, food & beverage equipment, pressure vessels, heat exchangers, and piping systems, AISI 316Ti provides reliable performance under harsh conditions. Available in sheets, plates, bars, tubes, and custom-fabricated components, our products fully comply with ASTM A312, ASTM A479, EN 1.4571 standards, making them trusted by global manufacturers, suppliers, and fabricators seeking high-strength, corrosion-resistant stainless steel solutions.
01
High Quality
02
Advanced Equipment
03
Professional Team
04
Custom Service
Specifications (Metric & Imperial) - AISI 316Ti
| Form / Shape | Metric Range | Imperial Range | Notes / Remarks |
|---|---|---|---|
| Sheet / Plate | Thickness: 0.3 – 200 mm Width: 1,000 – 3,500 mm Length: 1,000 – 6,000 mm | Thickness: 0.012" – 7.87" Width: ~39" – 138" Length: ~39" – 236" | Cold-rolled sheet, hot-rolled plate, coil, large plates |
| Strip / Coil / Thin Gauge | Thickness: 0.3 – 10 mm Width: 7 – 1,250 mm | Thickness: 0.012" – 0.394" Width: ~0.28" – 49" | Strip, coils, thin-gauge applications |
| Round Bar / Rod | Diameter: 4 – 600 mm Length: 400 – 12,000 mm | Diameter: 0.157" – 23.62" Length: 15.7" – 472" | Standard stock; can be customized |
| Flat / Square / Rectangular Bar | Width: 20 – 800 mm Thickness: 3 – 60 mm | Width: 0.79" – 31.5" Thickness: 0.12" – 2.36" | Includes flat, square, angle, rectangular bars |
| Pipe / Tube - Round (Seamless & Welded) | OD: 6 – 610 mm Wall Thickness: 0.5 – 100 mm Length: 1,000 – 12,000 mm | OD: 0.236" – 24.0" Wall Thickness: 0.020" – 3.94" Length: 39" – 472" | Seamless, welded, ERW/LSAW/SSAW options |
| Pipe / Tube - Square & Rectangular | Square: 10×10 – 100×100 mm Rectangular: 10×20 – 50×100 mm | Square: 0.39"×0.39" – 3.94"×3.94" Rectangular: 0.39"×0.79" – 1.97"×3.94" | Structural and custom profiles |
Physical & Material Data
| Property | Metric | Imperial | Notes |
|---|---|---|---|
| Density | 7.9 – 8.0 g/cm³ | 0.285 – 0.289 lb/in³ | Typical |
| Thermal Expansion | 16.5 µm/m·°C | 9.17 µin/in·°F | 20–100 °C |
| Modulus of Elasticity | 193 GPa | ~28,000 ksi | Typical |
Standards, Surface & Processing Options
| Category | Options / Notes |
|---|---|
| Standards | ASTM A312, ASTM A240, EN 1.4571, UNS S31635, JIS, DIN, GB |
| Surface Finishes | 2B, NO.1, BA, NO.4, Hairline, Polished, Mirror |
| Processing Services | Cutting, Custom Length, Bending, Welding, Straightening, Polishing |
| Notes | Custom sizes, thickness, OD, wall, and profiles available on request |
Key Features
Excellent Corrosion Resistance: Resistant to chloride-induced pitting and intergranular corrosion.
High-Temperature Stability: Titanium stabilization prevents carbide precipitation.
Durable & Long-Lasting: Maintains mechanical strength under harsh conditions.
Versatile Applications: Available in sheets, plates, bars, tubes, and custom-fabricated components.
International Standards Compliance: ASTM, EN, and UNS certified.
Products Applications
Chemical processing equipment
Marine & offshore components
Food & beverage industry machinery
Heat exchangers & pressure vessels
Piping systems & custom industrial fabrication
Inspection & Quality Assurance
Material Testing: Mechanical, chemical, and corrosion tests per ASTM and EN standards.
Surface Inspection: Visual and ultrasonic testing to ensure defect-free surfaces.
Third-Party Verification: Optional inspection by SGS, TUV, or other international agencies.
Traceability: Full mill test certificates (MTC) provided with each shipment.
We provide full technical support, certification documents, and assistance with logistics and delivery for international shipments.
Our address
Room 4107, Runfeng Building, Sanqiao New Street, Weiyang District, Xi'an City, Shaanxi Province
Phone Number
+86 15769214734
FAQ
Q1: What forms of AISI 316Ti are available?
A1: Sheets, plates, bars, tubes, and custom-fabricated components.
Q2: Which standards do your AISI 316Ti products meet?
A2: ASTM A312, ASTM A240, ASTM A276, EN 1.4571, UNS S31635.
Q3: Can you provide custom sizes or profiles?
A3: Yes, we offer fully customized dimensions, wall thickness, OD, lengths, and special profiles according to your requirements.
Q4: Which industries commonly use AISI 316Ti?
A4: Chemical processing, marine & offshore, food & beverage equipment, heat exchangers, pressure vessels, and industrial piping.
Q5: How is product quality ensured?
A5: We perform chemical & mechanical testing, visual & ultrasonic inspections, and optional third-party verification (SGS, TUV, etc.). Each shipment comes with a full mill test certificate (MTC).
Q6: What surface finishes and processing services are available?
A6: Surface finishes include 2B, NO.1, BA, NO.4, Hairline, Polished, and Mirror. We also provide cutting, bending, welding, straightening, and polishing services.
Q7: What is the typical lead time for orders?
A7: Stock items are usually shipped within 1–3 weeks. Custom orders depend on size, quantity, and processing requirements.
