Rock Wool Sandwich Panels are widely recognized as one of the most reliable fire-resistant and thermally insulated building materials for modern construction. Manufactured using high-density mineral wool core and durable steel sheets, these panels provide superior fire protection, energy efficiency, and sound insulation. As a professional sandwich panel manufacturer, we supply customized rock wool panels for industrial, commercial, and infrastructure projects worldwide, meeting international standards such as EN, ASTM, and ISO.
01
High Quality
02
Advanced Equipment
03
Professional Team
04
Custom Service
Product Specifications
| Item | Specification |
|---|---|
| Panel Type | Wall Panel / Roof Panel |
| Core Material | Rock Wool (Mineral Wool) |
| Density | 80 – 150 kg/m³ |
| Thickness | 50 / 75 / 100 / 150 / 200 mm |
| Width | 950 mm / 1000 mm |
| Length | Customized (up to 12m) |
| Steel Sheet Thickness | 0.3 – 0.8 mm |
| Surface Coating | PE / PVDF / HDP |
| Fire Rating | A1 Non-Combustible |
| Thermal Conductivity | ≤ 0.044 W/m·K |
| Sound Insulation | ≥ 30 dB |
| Color | Customized (RAL Color System) |
Metric & Imperial Size Table
| Thickness (mm) | Thickness (inch) | Width (mm) | Width (inch) |
|---|---|---|---|
| 50 mm | 2.0" | 950 / 1000 | 37.4" / 39.4" |
| 75 mm | 3.0" | 950 / 1000 | 37.4" / 39.4" |
| 100 mm | 4.0" | 950 / 1000 | 37.4" / 39.4" |
| 150 mm | 6.0" | 950 / 1000 | 37.4" / 39.4" |
| 200 mm | 8.0" | 950 / 1000 | 37.4" / 39.4" |
Key Features
🔥 Excellent Fire Resistance
A1 grade non-combustible core
Withstands temperatures over 1000°C
Ideal for high fire safety requirements
🌡️ Superior Thermal Insulation
Reduces energy consumption
Maintains stable indoor temperature
🔇 Soundproof Performance
Effective noise reduction
Suitable for industrial & urban buildings
💪 High Strength & Durability
مقا抗 deformation
Long service life
🌍 Eco-Friendly Material
Non-toxic & recyclable
Meets green building standards
Applications
Industrial factories & workshops
Steel structure warehouses
Cold storage buildings
Clean rooms & pharmaceutical plants
Power plants & petrochemical facilities
Airports, stadiums, exhibition halls
OEM & Customization
We provide full customization services:
Panel thickness & density adjustment
Steel coating (GI / PPGI / Stainless Steel)
Fire rating certification customization
Length & joint design (Hidden / Overlap)
Special environments (marine / desert / high humidity)
Inspection & Quality Assurance
We implement a strict quality control system:
Raw material inspection (rock wool density & purity)
Online production monitoring
Thickness & bonding strength testing
Fire resistance testing (A1 standard)
Third-party inspection available (SGS / BV / TUV)
Product Delivery Standards
Standard export seaworthy packaging
Protective film on steel surface
Wooden pallet or steel frame packing
Container loading optimization (20GP / 40HQ)
Global shipping support (FOB / CIF / DDP)
Why Choose Us
🏭 Direct factory manufacturer
🌍 Exported to 50+ countries
📐 Full OEM & engineering support
🔥 Certified fireproof performance
🚀 Fast production & delivery
FAQ
1. What is a Rock Wool Sandwich Panel?
A Rock Wool Sandwich Panel is a composite building material made of two metal sheets bonded with a high-density mineral wool core, designed for fire resistance, thermal insulation, and soundproofing.
2. What is the fire rating of rock wool panels?
Rock wool panels are classified as A1 non-combustible, meaning they provide the highest level of fire protection and do not contribute to fire spread.
3. What thickness should I choose?
50–75 mm → Standard wall insulation
100–150 mm → Industrial & commercial buildings
150–200 mm → Cold storage / high insulation demand
4. Are rock wool sandwich panels waterproof?
The panels are water-resistant, but not fully waterproof. Proper sealing and installation are required to ensure long-term performance.
5. Can the panel size be customized?
Yes, we support full customization, including:
Length (up to 12 meters or more)
Thickness
Steel sheet type & coating
Joint system design
6. What steel materials are available?
We offer multiple surface options:
PPGI (Pre-painted Galvanized Steel)
GI (Galvanized Steel)
Stainless Steel
Aluminum Sheet
7. What is the lifespan of rock wool sandwich panels?
Typically 15–30 years, depending on environment, coating type, and maintenance.
8. Are these panels suitable for roofing?
Yes, we provide both wall panels and roof panels, with different profiles and connection systems.
9. Do you provide certifications?
Yes, we can provide:
SGS / BV / TUV inspection reports
ISO certification
Fire resistance test reports (A1 standard)
10. What industries use rock wool sandwich panels?
Widely used in:
Steel structure buildings
Warehouses & factories
Cold storage facilities
Clean rooms & pharmaceutical plants
Power plants & petrochemical projects
11. What is the difference between rock wool and PU sandwich panels?
Rock Wool Panel → Better fire resistance (A1)
PU Panel → Better thermal insulation but lower fire rating
12. How are the panels installed?
Panels are installed using:
Hidden screw systems or overlap joints
Steel structure framing
Sealing materials for insulation and waterproofing
