6061 Aluminium Sheet is a precipitation-hardened aluminium-magnesium-silicon alloy widely used for structural, mechanical, automotive and aerospace applications. Known for its excellent strength-to-weight ratio, good corrosion resistance, weldability, and machinability, 6061 is one of the most versatile aluminum alloys available.
Our factory supplies 6061-T6 / T651 aluminium sheets and plates produced in accordance with ASTM B209, EN 485, and GB/T 3880, with guaranteed dimensional accuracy, mechanical strength, and surface quality for global B2B customers.
01
High Quality
02
Advanced Equipment
03
Professional Team
04
Custom Service
6061 Aluminium Sheet
Aluminium 6061 Sheet is a precipitation-hardened aluminium alloy, containing magnesium and silicon as its major alloying elements. Originally called "Alloy 61S".
6061 Aluminium Sheet is a medium to high strength heat-treatable alloy with a strength higher than 6005A. ASTM B209 6061 Aluminium Sheet has very good corrosion resistance and very good weldability although reduced strength in the weld zone. It has medium fatigue strength. It has good cold formability in the temper T4, but limited formability in T6 temper. Not suitable for very complex cross sections.
Core features
High strength and light weight
6061 aluminum alloy has the characteristics of high strength and light weight, its tensile strength can reach 290 MPa, the yield strength is 241 MPa, and the elongation is 8%-12%.
Good corrosion resistance
It has good corrosion resistance in most environments, especially in corrosive environments such as seawater.
Excellent processability
Easy to cut, form, and weld, suitable for various machining processes such as milling, drilling, stamping, etc.
Heat-treatability
Its strength and hardness can be improved by T6 treatment, which is suitable for applications with high performance requirements.
Common uses
► Aerospace: used in the manufacture of aircraft structural parts, engine parts, etc.
► Automobile manufacturing: suitable for body, frame, chassis and other parts to improve fuel efficiency.
► Construction industry: used for doors and windows, curtain walls, decorative materials, etc.
► Electronics: used in mobile phone cases, computer frames, radiators, etc.
Standard Dimensions of 6061 Aluminium Sheet
| Alloy | ASTM B209 1050, 1060, 1100, 1235, 3003, 3004, 3105, 5052, 5754, 6061, 8011 |
|---|---|
| Aluminium 6061 Sheet Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium 6061 Sheet Thickness | 0.5mm-150mm |
| Aluminium 6061 Sheet Width | 500-2000mm |
| Aluminium 6061 Sheet Length | to clients' requirement |
| Aluminium 6061 Sheet Coating | Polyester, Fluorocarbon, polyurethane and epoxy coating |
| 6061 Aluminium Sheet Coating finish | PVDF, POLYESTER(PE) |
| Surface | Bright, polished, hair line, brush, sand blast, checkered, embossed, etching, etc. |
| Gloss | Meet the customer requirement |
| Total coating thickness | PVDF coating: More than 25 micron; Polyester coating: More than 18 micron |
| Coating hardness | (pencil hardness) more than 2H |
| Coating adhesive | No lower than1st grade |
| Impact resistance | No cracking or peeling (50kg/cm, ASTMD-2794: 1993) |
| Flexibility (T-bend) | 2T |
| MEK resistance | More than 10 |
| Available Aluminium 6061 Sheet Stock Sizes | 1ft x 1ft, 1ft x 2ft, 1ft x 4ft, 2ft x 2ft, 2ft x 4ft, 4ft x 4ft, 4ft x 8ft, 4ft x 10ft or Cut to Size or Custom Shape. |
| Aluminium 6061 Sheet Packaging Details | Standard export package. One pallet is about 2-3 ton.Two steel belts in width and three in width. One 20GP container can load about 18-20 tons Aluminium 6061 Sheet. One 40GP container can load about 24 tons Aluminium 6061 Sheet |
Wall Thickness Grades (Industrial Classification)
| Thickness | Category | Typical Use |
|---|---|---|
| 0.8–3 mm | Thin Sheet | Panels, covers, casings |
| 3–10 mm | Medium Plate | Machinery, transportation |
| 10–25 mm | Thick Plate | Tooling, fixtures |
| 25–150 mm | Heavy Plate | Mold bases, aerospace |
| 150–250 mm | Ultra-Thick Block | CNC machining, die making |
Mechanical Properties (Typical 6061-T6)
| Property | Typical Value |
|---|---|
| Tensile Strength | 290 MPa (42 ksi) |
| Yield Strength | 240 MPa (35 ksi) |
| Elongation | 8–12% |
| Brinell Hardness | 95 HB |
| Modulus of Elasticity | 69 GPa |
| Density | 2.70 g/cm³ |
Chemical Composition (6061 Alloy)
| Element | % |
|---|---|
| Mg | 0.8 – 1.2 |
| Si | 0.4 – 0.8 |
| Cu | 0.15 – 0.40 |
| Cr | 0.04 – 0.35 |
| Fe | ≤ 0.70 |
| Zn | ≤ 0.25 |
| Mn | ≤ 0.15 |
| Ti | ≤ 0.15 |
| Al | Balance |
Key Features
✔ High strength-to-weight ratio
✔ Excellent weldability (T4/T6)
✔ Good corrosion resistance
✔ Excellent machinability (T651)
✔ Good anodizing response
✔ Stable mechanical performance
✔ Suitable for CNC machining and precision components
Certifications & Standards
► International standards: ASTM B209, ISO 9001
► Heat treatment state: O (annealed), H12 (semi-hard), H14 (hard), H16 (harder), H18 (extra hard), H22, H24, H26, etc
We have advanced production equipment and a strict quality inspection system, ensuring strict control at every stage from raw material procurement to production processing. High-quality aluminum is used as raw material to ensure the purity and quality of the products. During the production process, advanced techniques and technologies are employed to guarantee the clarity and uniformity of the patterns.
Our address
Room 4107, Runfeng Building, Sanqiao New Street, Weiyang District, Xi'an City, Shaanxi Province
Phone Number
+86 15769214734
FAQ – 6061 Aluminium Sheet
Q1: What is the difference between 6061-T6 and 6061-T651?
A1: T651 is stretched after heat treatment for better flatness, ideal for machining.
Q2: Is 6061 aluminum weldable?
A2: Yes, 6061 has good weldability, especially in T4 and O tempers.
Q3: What is the most popular thickness for 6061 sheets?
A3: 2mm, 3mm, 6mm, 10mm are the most common for export.
Q4: Can you provide anodized 6061 sheet?
A4: Yes, hard anodizing and decorative anodizing are available.
Q5: Do you provide CNC cutting for molds or aerospace parts?
A5: Yes, we offer precision cutting, milling, chamfering, and machining.
Q6: What certification is available?
A6: Mill Test Certificate (EN 10204 3.1), SGS, BV, TUV.
Q7: How is 6061 packaged for export?
A7: Moisture-proof packaging + steel pallet + corner protection.
Q8: Can you supply ultra-thick 6061 blocks?
A8: Yes, up to 250mm+ thickness.
Inspection & Quality Assurance
1. Raw Material Quality Control
Optical Emission Spectrometer (OES) chemical analysis
Hardness check for each batch
Surface defect inspection (scratch, dent, oxidation)
2. In-Process Control
Thickness deviation monitoring
Heat-treatment (T6/T651) consistency control
Flatness and diagonal inspection
Edge trimming and surface finish quality check
3. Final Inspection
Dimensional tolerance verification
Ultrasonic testing for internal defects (UT available)
Mechanical property test (tensile/hardness)
Surface film adhesion and protective coating test
4. Third-Party Testing
SGS / BV / TUV available upon request
Certificate: EN 10204 3.1 MTC
